FTTR Panel ONT — ZXEN G1015

The ZXEN G1015 is a panel GPON ONT for the FTTR-B small office scenario. It has a 2.488 Gbps downstream and 1.244 Gbps upstream GPON WAN port and a 2.5GE LAN port to provide up to 2 Gbps access for PCs and laptops.

Product Highlights

Green Design: · Automatically switches to the energy-saving mode according to the idle status of the port.
· The materials comply with RoHS standards.

Ultra-Gigabit Network: · Up to 2.5 Gbps symmetrical data rate for ultra high speed broadband access.

Flexible Management: · Plug & play, zero configuration.
· ZLife app for mobile management.

Product Parameters

WAN: GPON

LAN: 1 x 2.5GE RJ-45 ports

Dimensions: 89 x 89 x 28 mm

Key Functions: VPN: L2TP/PPTP/IPsec
Portal/802.1x authentication
Smart QoS
Cloud-based remote management (SCP)
ZLife app-based management
