ZTE D1001 LTE Router

The ZTE D1001 provides stable and cost-effective 4G cellular connectivity for a wide range of IoT deployments and other use cases requiring reliable mobile broadband. Designed to align with the global phase-out of 2G and 3G networks, it ensures a smooth transition to 4G.

Product Highlights

Compact Design
·Featuring compact dimensions of 70 x 70 x 23.5 mm and a weight of just 66.8 g, it is ideal for embedded and space-constrained applications.
Easy Deployment
·It simplifies deployment with wireless connectivity and two Ethernet ports, providing flexible networking for various needs.
High Reliability
·Designed for high reliability, it operates in temperatures from -10°C to +60°C and features a screw-fastened power connector for stable, secure operation.
High-Performance Connectivity
·It supports 3GPP Cat 4 standards, delivering speeds of up to 150 Mbps downlink and 50 Mbps uplink—ideal for real-time applications. An external antenna port is included for enhanced signal reception.
Secure Remote Access & Control
·The D1001 provides secure and controllable remote management services, supporting SMS-based remote control, TR-069 (ACS) remote management, and SSH access (can be enabled via ACS).

Product Parameters

LTE
LTE FDD(Category 4) DL 150Mbps，UL 50Mbps
LTE TDD(Category 4) DL 110Mbps，UL 10Mbps
Interface
USB interface×1 Only for debug and manufacture
RJ45 interface×2 100M interface
Antenna interface×1
USIM/SIM slot
4FF SIM eSIM (Customizable)
Power
AC adapter 12V/1A
Environment
Operating temperature -10℃ ~ +60℃
Storage temperature -30℃ ~ +70℃
Humidity 5%~ 95%
Physical Properties
Dimensions 70(W) X 70(L) X 23.5(T) mm
Weight about 66.8g
Others
LED Power indication LED,Network indication LED
Button Reset button
