ZXONE 8000 Intelligent OTN Equipment

Overview

ZXONE 8000 is large-capacity cross-connected equipment. It supports 10G/100G/400Gb/s, enabling large-capacity ODUk electrical cross connection and optical cross connection at wavelengths of 10G/100G/400Gb/s.

Product Features

Large-capacity ODUk electrical cross-connect

● ZXONE 8000 supports large-capacity electrical cross-connect of 0.8T/1.4T/2.8T/3.2T/9.4T and enables non-blocking electrical cross-connect of multi-granularity services including ODU0/1/2/2e/3/4/flex; it can be deployed at aggregation/core nodes in the network.It supports VC cross-connection,to meet the customers' requirement for TDM service.

OTDR function

● Easy to find the fiber length, fiber attenuation, fiber broken point, and optical fiber fusion point position. Support real-time query and detection system. Make daily maintenance and troubleshooting easier.

O/E hybrid cross-connect and intelligent dispatching

● The optical layer supports 2-20-degree ROADM, N*M WSS, directionless, colorless, and contentionless. It can implement automatic E2E configuration of wavelengths.

● It supports WASON control plane in optical and electrical layer.

Excellent 100G transport capability

● 100Gb/s system adopts PM-QPSK encoding and SD-FEC technology with good OSNR tolerance.

● ZXONE 8000 supports beyond 100G optical networks with 400G per wavelength , providing larger bearing capacity.

PIC (photonic integrated circuit)

● Single sub-rack can support service access, cross-connection, MUX/DEMUX, optical amplification, clock processing and transmission functions. By adopting PIC technology, lower power consumption and cost-effective can be realized.

Synchronization

● Support 1588V2 transmission and synchronous Ethernet transmission.

High integration, eco-friendly and energy-saving feature

● 100G line side board support coherent CFP module, greatly reduce the power consumption of the system.

● It adopts ASIC chips integrated with more functions so that it dramatically reduces overall PCB calorific value and energy consumption.

Highly reliable system architecture

● Adopt redundant 1+1 hot backup for main control unit, power supply unit and clock unit.

● The cross-connect unit uses advanced cubic protection, which is more than three orders of magnitude higher than common 1+1 protection. It greatly improves the security of the equipment.

Reliable carrier-class protection

● Support fiber-level, λ-level, sub-λ-level and L2 protection modes:

● Fiber-level: line 1+1 protection, optical multiplex section 1+1 protection;

● λ-level: optical channel 1+1 protection;

● Sub-λ-level: ODUk 1+1 protection;

● L2: ESR protection
