ZXWE WN3722-X
ZXWE WN3722-X is a Wi-Fi 7 indoor XGS-PON uplink wireless access point. It uses a dual-RF design in 2.4GHz and 5GHz to provide a maximum access rate of 3.57Gbps. It is especially suitable for indoor scenarios such as offices, meeting rooms, service centers, hotel halls, and indoor hotspots. The product supports two operation modes: FAT AP/ FIT AP mode. In FIT AP mode, it can be managed in a unified and centralized manner together with the wireless controller.
Product Parameter
| Model | Parameter | |
|---|---|---|
| Dimension | 220 mm*220 mm*39 mm (W*D*H) | |
| Uplink | XGS-PON, 2.5GE | |
| Downlink | 4* GE, RJ11 TEL | |
| Maximum Access Rate | 3.57Gbps | |
| RF Design | 2.4GHz, 2×2:2 MU-MIMO; 5GHz, 2×2:2 MU-MIMO | |
| Maximum number of access users per RF | 512 | |
| Weight | 0.52kg | |
| Power Supply | POF 54V 0.45A; POE IEEE 802.3af/at ; DC 12V/2.0A | |
| Operating Temperature | -10ºC - 45ºC | |
| Operating Relative Humidity | 5% - 95%(Non-condensing) | |
