ZXDUPA-WR12
ZXDUPA-WR12 （One-Cabinet Site） is ZTE new generation of outdoor DC power system, which can provide -53.5V DC rated output voltage power for communications equipment. It supports multiple energy resource utilization, including mains, diesel generator and solar. It has highly integrated structure design to save site footprint. Key components of the power system adopt modular design, support site smooth evolution from 4G to 5G with better CAPEX. Based on component-site-network 3 levels smart cloud management, whole network energy efficiency can be optimized and reduce the OPEX of O&M.
Highlights
Simpler Structure Design
- Only need one cabinet to support 24KW output capacity and 2groups 12V Lead Acid battery or 4PCS 3U lithium battery, satisfy 3G/4G/5G co-site and sharing site power supply requirement. Compared with traditional site power system, save 50% site footprint
- Unified power platform and key components with modular design, support smooth evolution for future 5G and low-carbon application
- Multiple cabinet choice, adopts multiple large capacity cooling device like air-conditioner/ heat-exchanger/DC fan, satisfy heat dissipation requirement for 5G
Efficient and Green
- Super high efficiency rectifier, peak efficiency≥97%, save more power loss during conversion process
- Support smooth solar access, MPPT units with 99.9% statistic tracking precision, make full utilization of solar resource, contributes to site carbon-neutral
- Voltage boosting for remote power supply, achieve 100% battery capacity utilization, and reduce cable loss
Smart Management
- Smart grid peak shaving, supports dynamic collaboration of rectifier and battery, achieve free grid modernization of site 5G evolution
- Smart metering, separated metering and billing for 3G/4G/5G device, achieve differential battery backup strategy to save investment cost
- Smart cloud management, achieves visible whole network site operation status view, provides O&M support guidance to reduce on-site visit, accurate energy efficiency analysis to improve network EE and save OPEX
Product Parameter
| Model | Parameter | |
|---|---|---|
| Model Type | ZXDUPA-WR12 | |
| AC Input Type | Three-phase five-wire (L1/L2/L3/N/PE) | |
| Rectifier Power Density | 70.2 W/in3 | |
| Rectifier Working Temperature | -40℃ ～75℃ | |
| Rectifier Efficiency | Max. 97% | |
| DC Lightning Protection | In: 10kA(8/20μS) for rectifier | |
| Rectifier Rated Output Power | 4000W | |
| Environment Interface | 4 for battery/ambient temperature(configurable), 1 for door magnetic, 1 for humidity, 1 for flooding and 1 for smoke |
|
| Relays (Dry Contacts) Interface | 8 for output dry contact, 8 for input dry contact | |
| MTBF | ≥2*105 hours | |
| Communication Interface | 1*RS232/RS485, 1*RS485, 1*FE, 1*USB | |
| Rectifier Dimension | 40.8mm×84.5mm×292.5 mm(H×W×D) | |
| CSU603A Dimension | 4U width, 1U height | |
| AC Input | 85 AC- 300V AC@50 Hz / 60Hz | |
| Altitude | 0 to 2000 m: 100% output power; 2000 to 3000 m: The power derating percentage is 1% when the altitude increases by 100 m. Customer shall use system under derating consideration. |
|
| Certification | EN61000,DIN/EN 55022,ETSI EN 300 386, IEC 61000,EN 55032, CISPR 32 UL/IEC/EN 62368. IEC 60950-22, EN 60950-22 IEC 60068, IEC 60529 GB/T 2423. 56-2006, IEC 60068-2-64:2008 |
|
| AC Lightning Protection | Class B+C 30kA (8/20μs) | |
| Load Distribution | Flexible configuration, LLVD1:16poles LLVD2:12poles |
|
| Battery Distribution | 2×125A/1P MCBs | |
| Output Voltage | -53.5VDC (-42VDC～-58VDC adjustable) | |
| AC Input | 1*63A/4P MCB | |
| Max. Capacity | 24kW, 6pcs rectifier at full configuration | |
| Heat dissipation and climate control device(customized) | -Air-conditioner (with power saving features when AC mains OFF) -Heat-exchange -Ventilation Fan -Heater |
|
| Environment | Operating temperature: -40 ℃ to +45 ℃; Relative operating humidity: until 95 % (not condensing); Storage temperature: -40 ℃ to +70 ℃; Relative storage humidity: until 95 % (not condensing); Air pressure: 80kPA to 106kPA |
|
