Product Overview
PadPower
ZXDD01 D2000 V5.5R01 is an outdoor DC power product. It converts AC input into DC output (rated 57VDC/2000 W) and is compatible with high-voltage DC input. The system can support smooth capacity expansion or connect PadBattery for power backup. With modular integration design, the D2000 can be fast deployed and installed on the wall or on the pole to save footprint.
Highlights
Fast deployment, 1 person 1 hour
-- Compact structure, 7.5L small volume, only 1/8 of the traditional wall-mounted power
-- Quick-plug terminals for input and output, plug and play
-- Supporting pole-mounted and wall-mounted,“0” footprint and “0” site rental
High efficiency, energy saving, carbon emission reduction
-- Peak efficiency: ≥96.5% @220VAC; Efficiency: ≥96% @full load
-- Natural cooling, “0” cooling consumption
-- Power supply near telecom equipment to reduce cable loss and save energy
High environment adaptability, maintenance-free
-- IP65, applicable for harsh environment
-- Natural heat dissipation design, suitable for operation temperature up to 60°C
-- Natural cooling and no fan design, maintenance-free
Wide input voltage range, multiple Input modes
-- Support 85-300V AC or 90-400V DC input
-- High adaptability to 110VAC/ 220VAC grid power and 240VDC/ 336VDC HVDC input
Smooth capacity expansion
-- Max. 2pcs of D2000 parallel operation
-- Max. 8pcs of 50Ah Pad batteries parallel connection to meet longer backup time
Intelligent management
-- Optional embedded 4G & WiFi modules
--Support 4G networking for remote management and mobile APP for near-end maintenance& data check through WiFi
Learn more
Product_Parameter
| Model | Parameter(Operator) | Parameter(Enterprise) |
|---|---|---|
| AC/DC input voltage | 110/220 VAC（85 VAC-300 VAC） 240VDC/336VDC（90VDC-400VDC） | |
| Frequency | 50 Hz/60 Hz （45 Hz～66 Hz） | |
| Intelligent management (option) | Embedded 4G & WiFi modules Support 4G networking/ SNMP protocol for remote management; Mobile APP for near-end maintenance& data check through WiFi | |
| Alarm | Input under-voltage & over-voltage alarms, Over-temperature alarm, Output over-voltage & over-current alarms ,etc. | |
| DC output terminals | Load: 3*40A, quick plug terminals with replaceable fuse Battery: 1*63A, quick plug terminal (for battery connection/ large capacity DC load connection/ PadPower smooth expansion) | |
| Dimension | 440*55*310(mm, H*W*D) (Excluding handle and waterproof plug) | |
| Weight | 8.5kg | |
| Cooling mode | Natural heat dissipation | |
| Noise | ≤40dB | |
| Efficiency@220VAC | ≥96.5%(peak efficiency)，≥96% (full load) | |
| Rated output voltage | 57V DC | |
| Rated output power | 2000W @220VAC | |
