Product Overview
ZXV10 B836CT-A15
ZXV10 B836CT-A15 is a Ultra high definition STB. It's equipped with the latest high performance and low power SOC coming from Amlogic, it supports Google CBS and it is compatible with DVB-C/T/T2 standard, The SOC has up to 24000 DMIPS processing capacity, support HEVC and AV1 decoding. It could provide the customer with a fluent and responsive user experience, help the operator offer the stable services to the subscribers.
Product Parameter
| Model | Parameter | |
|---|---|---|
| CPU | Powerful Quad-core ARM Cortex A55, up to 24000 DMIPS | |
| GPU | 3D GPU with ARM Mali-G31 GPU MP2 | |
| Memory | Flash Memory: 16GB eMMC RAM: 3GB DDR4 | |
| Size & Weight | 120 mm*120 mm*23 mm; ≤1kg | |
| Video | VP9 Profile-2 up to 4Kx2K@60fps； AV1 MP-10@L5.1 up to 4Kx2K@60fps； H.265 HEVC MP-10@L5.1 up to 4Kx2K@60fps； H.264 AVC HP@L5.1 up to 4Kx2K@30fps； H.264 MVC up to 1080p@60fps； MPEG-4 ASP@L5 up to 1080p@60fps (ISO-14496)； MPEG-2 MP/HL up to 1080p@60fps (ISO-13818)； MPEG-1 MP/HL up to 1080p@60fps (ISO-11172) | |
| Audio | MPEG 1 Layer I/II, MP3, MPEG-4 AAC, Dolby Digital/Dolby Digital Plus | |
| Ethernet | 10/100 Base-T Ethernet RJ45 | |
| RF IN | Female, 75 ohm IEC61169-2 | |
| USB | 2*USB 2.0 | |
| HDMI | 1*HDMI, HDMI 2.0b / HDCP 2.2 | |
| SPDIF | 1*S/PDIF Optical | |
| SD reader | 1*Micro-SD reader | |
| Others | 12V DC input | |
| Wi-Fi | Wi-Fi 6 2*2, Dual band, 2.4GHz/5GHz | |
| RCU | 1*BT&IR Basic remote control | |
| OS | Android 10 operating system | |
| CAS/DRM | Widevine/Playready | |
| Tuner Type | DVB-T/T2 compliant | |
| Frequency Range | 47-872MHz | |
| Certification | CE | |
| Power | Power Mode:AC-DC Adaptor; Input Voltage:100-240VAC, +/-10%, 50/60Hz; Output Voltage:12V | |
